Ophthalmic Electric Chair
Shipped From Abroad
Features:1.Up and down moving range, 2.Chair rotation angle, 3.Backrest adjustment angle, 4.Headrest adjustable range
Delivery & Availability:
Typically 10-21 working days – excluding furniture and heavy/bulky equipment. Please contact us for further information
Description
Ophthalmic Electric Chair is used by eye doctors to provide eye care. They are used to check the eyes for any diseases or conditions. These Ophthalmic Chair and a Stand allows doctors to take a professional look at your eyes.
Specifications of Ophthalmic Electric Chair:
| EC-300 | ||
| Mechanical Parameters | 1.Up and down moving range | 568~708mm |
| 2.Chair rotation angle | 0°~270° | |
| 3.Backrest adjustment angle | 80°~180° | |
| 4.Headrest adjustable range | within a semicircle area of 250mm radius | |
| 5.Chair max load | 150kgs | |
| Electrical Parameters | Input voltage | 110-115V AC 50Hz~60Hz240V AC 50Hz/60Hz |
| Output voltage | 100-115V AC 50Hz/60Hz(The optional) 240V AC 50Hz/60Hz | |
| Engine power | 28V 1.5A DC | |
| Fuse | 5A 130/250V AC | |
| No load power | 1W | |
| Pressure test | 2KV | |
| Main wire | 10A 120V/250V | |
| Working mode | S1 | |
| Working temperature | -10ºC~+40ºC | |
| Relative humidity | less than 90% | |
| Installation Dimension | Figure size | 1884mm*1316mm*1663mm |
| Weight | 145kgs | |
