20–60 PSI High Pressure Oxygen Concentrator JAY-20-4.0

Shipped From Abroad

High-capacity oxygen concentrator offering 1–20 L/min at 20–60 PSI. Designed for larger medical facilities requiring a robust and reliable oxygen source.

Delivery & Availability:
Typically 10-21 working days – excluding furniture and heavy/bulky equipment. Please contact us for further information.

Description

The JAY-20-4.0 high-pressure oxygen concentrator is engineered for medical environments that demand higher oxygen flow rates. Delivering 1 to 20 L/min at an outlet pressure of 20–60 PSI (0.14–0.4 MPa), this unit ensures a steady and pure oxygen supply with a concentration of 93% (±3%). Its durable construction and advanced features support continuous operation in demanding settings such as intensive care units and operating rooms.

Key Features

Flow Rate: 1–20 L/min
Oxygen Concentration: 93% (±3%)
Outlet Pressure: 20–60 PSI (0.14–0.4 MPa)
Power Consumption: ≤2200W
Sound Level: ≤60 dB
Net Weight: 118 kg
Alarms:
- Power failure alarm
- High and low pressure alarm
- Low oxygen concentration alarm: Blue light (>82%), Red light (<82%)
Mobility: Equipped with wheels for easy transportation
Applications:
- Connects with ventilators and anesthesia machines in ICU and operating rooms
- Suitable for hospitals with up to 100 beds
- Compatible with hyperbaric oxygen chambers
