20-60PSI High Pressure Oxygen Concentrator

Shipped From Abroad

Industrial-grade oxygen concentrator delivering 1–40 L/min at 60 PSI. Suitable for large-scale medical facilities and specialized applications requiring high oxygen flow.

Delivery & Availability:
Typically 10-21 working days – excluding furniture and heavy/bulky equipment. Please contact us for further information.

Description

The JAY-40-4.0 is a high-pressure oxygen concentrator designed for large medical institutions and specialized applications. It provides an adjustable flow rate of 1 to 40 L/min with a consistent outlet pressure of 60 PSI (0.4 MPa). The unit maintains an oxygen concentration of 93% (±3%) and features a high-efficiency three-tower adsorption system for enhanced durability. Its robust design ensures reliable performance in intensive care units, operating rooms, and hyperbaric oxygen therapy chambers.

Key Features

Flow Rate: 1–40 L/min
Oxygen Concentration: 93% (±3%)
Outlet Pressure: 60 PSI (0.4 MPa)
Power Consumption: ≤4440W
Net Weight: 256 kg
Alarms:
- Power failure alarm
- High and low pressure alarm
- Low oxygen purity alarm
Design: Compact and mobile with integrated pressure gauge and automatic dehydrator/refrigerated air dryer
Applications:
- Connects with ventilators and anesthesia machines in ICU and operating rooms
- Compatible with hyperbaric oxygen chambers
